Home/ Products / DC6040A Mini CNC Milling Machine
DC6040A Mini CNC Milling Machine
The DC6040A Mini CNC Mill stands out by combining precision, stability, and user-friendliness in a compact design, making it ideal for diverse home and small-scale metalworking applications.
Ningbo Kaibo CNC Machinery Co., Ltd. Ningbo, Zhejiang, China
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240820135341/6产品two-phase-home-use-mini-cnc-milling-machine-for-metal-dc6040a-1.png
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807110939/two-phase-home-use-mini-cnc-milling-machine-for-metal-dc6040a-2.jpg
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807110939/two-phase-home-use-mini-cnc-milling-machine-for-metal-dc6040a-3.jpg
Product Parameters
Accuracy
positioning accuracy: 0.01 mm
Repeatability: 0.005 mm
See more
Workbench
working desk size: 620*455mm
T-slot dimensions: 4T-12-120 mm
Maximum load: 150 kg
Processing range
X/Y/Z axis travel: 600/400/140 mm
Gantry width: 705 mm
Beam to workbench: 300 mm
Spindle nose to worktable: 140-280 mm
Door opening width: 540 mm
Feed
Maximum feed speed G00: 15 m/min
Maximum processing speed G01: 10 m/min
X/Y/Z axis motor power: 400/400/400 W
Spindle
Spindle motor power: 1.5KW
Maximum spindle speed: 24000 rpm
Tool holder: ER16(φ3.17-φ8)
Spindle diameter: 85 mm
Common
Power supply and total capacity: 1P/220V/50Hz/5KVA
Machine weight: 2000 kg
aspect: 1810*1550*1870mm
The main components
Controller: Syntec 21MA/Taiwan
AC servo motor (driver): Yaskawa/Japan
Spindle inverter: Innovation/China
Linear Guides: 20 Hiwin, PMI/Taiwan
Ball Screw: 2005 Hiwin, PMI/Taiwan
Electronic handwheel: EHDW-BA5S-1 Future/Taiwan
Lubrication system: YET-A2P2 ISHAN/Taiwan
Oil Cooler: Opt.Parsonthor/China
air conditioner: Opt.Parsonthor/China
Pneumatic system: AirTac/Taiwan
Close
Product Details
Product Introduction
The single-phase household small metal CNC milling machine DC6040A is the smallest model of Kaibo CNC. It is a gantry-type CNC milling machine. It is warmly welcomed by users for its high precision, low noise and strong stability.
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807110939/two-phase-home-use-mini-cnc-milling-machine-for-metal-dc6040a-4.jpg
Advantages and features
1. Adopt servo motor and precision ball screw, with high precision.
2. Low operating noise.
3. Strong stability.
4. It adopts 1.5KW high-precision frequency conversion spindle, which is easy to use.
5.Artistic and precise processing capabilities.
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807110939/two-phase-home-use-mini-cnc-milling-machine-for-metal-dc6040a-5.jpg
Application Scenario
1. Plastic mold
2. Shoe Model
3. Auto parts
4. Graphite
5. Roller
6. Hardware
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807110939/two-phase-home-use-mini-cnc-milling-machine-for-metal-dc6040a-6.jpg
Ordering Information
Custom Request
Our products support customization!
Packing and shipping
Support wooden box packaging and vacuum tin foil packaging;
All packaging complies with ocean, truck and railway standards;
Payment method
COMM
COMM
L/C
L/C
T/T
T/T
A/P
A/P
O/A
O/A
D/P
D/P
D/A
D/A
Refunds
If there is any problem with the product, please contact us at the first time.
Corporate Information
Ningbo Kaibo CNC Machinery Co., Ltd.
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240731151209/科学技术成果登记证书-精密高效快速数控钻铣复合加工中心的关键技术研究及产业化.jpg
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240731151209/科学技术成果登记证书-基于YSNTEC控制系统的图形对话式自动编程系统软件在高性能雕刻机中的应用.jpg
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240731151209/科学技术成果登记证书-五轴联动告诉精密雕铣机数控系统关键技术研究及开发.jpg
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240731151209/浙江制造认证证书%202024.11.27.jpg
100%
On-time delivery rate
Less than 3 hours
Response time
52000
Construction area
Service Guarantee
Service Information
Tel
+86-15805747758
Email
[email protected]
Address
Industry Area of ​​Changjie, Ninghai, Ningbo, Zhejiang, China
Call Now
Advisory Message
Pre-sales advice
Equipment can be customized according to your requirements (machine configuration, color...)
After-sales service
1. After-sales guarantee: We provide one-year free quality assurance service for the products we sell to ensure the stability and reliability of the products.
2. Technical support: The company has 26 sales service offices, equipped with professional technicians, who can answer customer questions online 24/7 and provide remote or on-site technical support.
3. Training service: Provide customers with free operation and maintenance training to ensure that customers can use and maintain the equipment proficiently.
4. Accessories supply: Provide original accessories for a long time to ensure the continuous and normal operation of customers' equipment.
5. Customer Feedback: Respond to customer feedback in a timely manner and continuously improve products and services to meet customer needs to the greatest extent possible.
Specific details
Please contact us
Product Specifications Reference
Spindle type
ER16/1.5kw/24000rpm electric spindle ER16/1.5-3kw/24000rpm constant power electric spindle ER20/3kw/24000rpm electric spindle ER25/4.5kw/24000rpm electric spindle NBT30/4.5kw/24000rpm electric spindle HSK E25/3kw/40000rpm electric spindle More spindles
